Wide range 342...528 V AC supply for operation on 380 V, 400 V or 480 V grids
US 208 V models available
High efficiency up to 95.5%
Output power rating: 30 kW per device, expandable up to 1920 kW
Output voltages: 60 V up to 2000 V
Output currents: 40 A up to 1000 A
Flexible, power regulated output stage
Various protection circuits (OVP, OCP, OPP, OTP)
5" TFT touch panel with display for values, status and notifications
Remote sensing with automatic detection
Galvanically isolated interfaces (USB, Ethernet, analog)
Integrated function generator with photovoltaics array simulation, including EN 50530
Internal resistance simulation and regulation
60 V models compliant to SELV
Discharge circuit (Uout < 60 V in ≤ 10 s)
Optional, digital interface modules
SCPI and ModBus RTU/TCP command set
LabView VIs and control software for Windows
