• AC wide range input 360-528 V, for 400 V and 480 V grids

• Energy recovery of the supplied DC energy into the local grid

• Galvanically isolated DC input

• Input power ratings up to 15 kW per unit, expand­able to 240 kW

• Input voltages up to 1500 V

• Input currents up to 510 A per unit

• FPGA based digital control

• Multilingual TFT touch panel

• User profiles, true function generator

• Galvanically isolated

• Master-slave bus for parallel connection

• Extra USB port on the front for USB stick

• Optional, digital, plug & play interfaces or alterna­tively installed IEEE/GPIB port

• SCPI command language supported

• Pluggable and retrofittable, digital interface modules for CAN, CAN­open, Ethernet (1 or 2 ports), Profibus, ProfiNet (1 or 2 ports), RS232, EtherCAT or ModBus TCP. See page 192.

• Three-way interface (3W) with a rigid GPIB port installed
